| Fiber Alignment | Ribbon |
| Fiber Type | SM (G.652); MM (G.651); DS (G.653); NZDS (G.655) |
| Fiber Dimensions | Single: Cladding diameter: 125㎛; Coating diameter 250: 900㎛ Ribbon: Cladding diameter: 125㎛; Ribbon fiber thickness 0.25 to 0.40mm |
| Fiber Setting & Cleaved Length | 10mm |
| Splicing Modes | Splice mode: 300, Heat mode: 100; Strip mode: 50 |
| Typical Splice Loss | SM: 0.05dB, MM: 0.02dB, DS: 0.08dB, NZDS: 0.08dB |
| Return Loss (dB) Min | > 60dB |
| Splicing Time | Typical 20 sec. with standard SM (ITU-T G.652) |
| Sleeve Heating Time | 1~2 core 20 sec.; 4-12 core 50 sec. |
| Applicable Protection Sleeves | 40mm, 60mm (fiber) |
| Storage of Splice Result | The last 10,000 results to be stored in the internal memory |
| Tension Test | 2N/4.4N |
| Storage Conditions | Temperature: 40°F~176°F, Humidity: 0~95% |
| Dimensions | 215mm x 136mm x 132mm (excluding bumper) |
| Number of Splice Cycles with Battery | Typically 236 Cycles |
| Electrode Life | 1,500 Splices |
| Blade Life | 3,650 Cleaves |
| Weight | 2.3kg (including battery) |
| Power Supply | 100~240V AC |
| Field of View | 20X |
| Magnification | 60X |
